Adjusting

Hotkeys

1 Source/Auto/Exit

2 Clear Vision/

3 Image Ratio/Volume/

4 Menu/Enter

5 Power

Menu/Enter

Press to display the OSD or conrm the selection.

Power

Press the Power button to turn on/o󰀨 the monitor.

Image Ratio/Volume/

When there is no OSD, Press Volume button to active volume adjustment bar, Press“ ” or “ ”to adjust volume. When

there is no OSD, press“ ”hotkey continuously to change 4:3 or wide image ratio. (If the product screen size is 4:3 or input

signal resolution is wide format, the hot key is disable to adjust).

Auto / Exit / Source hot key

When there is no OSD, Press Auto/Source button continuously about 2 second to do auto congure. When the OSD is

closed, press Source button will be Source hot key function. Press Source button continuously to select the input source

showed in the message bar, press Menu/Enter button to change to the source selected.

Questions and Answers:

Need help?

Do you have a question about the AOC 24B3HM and is the answer not in the manual?

AOC 24B3HM Specifications

General

Panel type	VA
Pixel pitch	0.275 x 0.275 mm
Screen shape	Flat
Pixel density	93 ppi
Backlight type	W-LED
Display diagonal	23.8 \
Surface hardness	6H
Anti-glare screen	Yes
Adobe RGB coverage	104 %
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
NTSC coverage (typical)	106 %
sRGB coverage (typical)	122 %
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	60.4 cm
Display brightness (typical)	250 cd/m²
AMD FreeSync type	FreeSync Premium Pro
Brand-specific features	False
Exterior finish type	Matt
Ethernet LAN (RJ-45) ports	0
Mean time between failures (MTBF)	50000 h
Certification	CB, CE, TUV-GS-MARK, EAC
Front bezel color	Black
Market positioning	Office
Tilt angle range	-5 - 23 °
Cable lock slot type	Kensington
Number of OSD languages	19
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
HDMI version	1.4
Headphone connectivity	3.5 mm
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Socket connector type	C5
Power consumption (typical)	- W
Package type	Box
Package depth	126 mm
Package width	614 mm
Package height	394 mm
Package weight	5020 g
Cables included	AC, HDMI
HDMI cable length	1.5 m

Weight and Dimensions
