AOC 27G2SAE User Manual

2
Power
The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the
type of power supplied to your home, consult your dealer or local power company.
The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will t
only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an
electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the safety purpose of
the grounded plug.
Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will protect the
monitor from damage due to power surges.
Do not overload power strips and extension cords. Overloading can result in re or electric shock.
To ensure satisfactory operation, use the monitor only with UL listed computers which have appropriate congured
receptacles marked between 100-240V AC, Min. 5A.
The wall socket shall be installed near the equipment and shall be easily accessible.

AOC 27G2SAE Specifications

General

Certification	ISO 9241-307
Product color	Black, Red
Detachable stand	Yes
Front bezel color	Black/Red
Market positioning	Gaming
NVIDIA G-SYNC	No
AMD FreeSync type	FreeSync Premium
AMD FreeSync refresh rate range	48 - 165 Hz
Panel type	VA
Pixel pitch	0.3114 x 0.3114 mm
Aspect ratio	4:3, 16:9
Screen shape	Flat
Pixel density	81 ppi
Backlight type	W-LED
Display surface	Matt
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Adobe RGB coverage	98 %
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	48 - 144 Hz
Horizontal scan range	30 - 160 kHz
Supported video modes	1080p
NTSC coverage (typical)	102 %
sRGB coverage (typical)	122 %
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.6 cm
Viewable size, horizontal	597.888 mm
Display brightness (typical)	350 cd/m²
HDMI version	1.4
DisplayPort version	1.2
Headphone connectivity	3.5 mm
Package type	Box
Package depth	187 mm
Package width	730 mm
Package height	520 mm
Package weight	6960 g
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	45 W
Power consumption (off)	0.3 W
Power consumption (typical)	26 W
Tilt angle range	-5 - 23 °
Cable lock slot type	Kensington
Number of OSD languages	19
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
RMS rated power	2 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Cables included	DisplayPort, HDMI
DisplayPort cable length	1.8 m
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	227.4 mm
Width (with stand)	612.5 mm
Height (with stand)	464.6 mm
Weight (with stand)	4630 g
Depth (without stand)	48.8 mm
Height (without stand)	365.8 mm
