AOC 27G2SAE User Manual

3
Installation
Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a
person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by
the manufacturer or sold with this product. Follow the manufacturer’s instructions when installing the product and use
mounting accessories recommended by the manufacturer. A product and cart combination should be moved with care.
Never push any object into the slot on the monitor cabinet. It could damage circuit parts causing a re or electric
shock. Never spill liquids on the monitor.
Do not place the front of the product on the oor.
If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit
instructions.
Leave some space around the monitor as shown below. Otherwise, air-circulation may be inadequate hence
overheating may cause a re or damage to the monitor.
To avoid potential damage, for example the panel peeling from the bezel, ensure that the monitor does not tilt
downward by more than -5 degrees. If the -5 degree downward tilt angle maximum is exceeded, the monitor damage will
not be covered under warranty.
See below the recommended ventilation areas around the monitor when the monitor is installed on the wall or on the
stand:
Installed with stand
Installed with stand
12 inches
30cm
4 inches
10cm
4 inches
10cm
4 inches
10cm
Leave at lease this
space around the set

AOC 27G2SAE Specifications

General

Certification	ISO 9241-307
Product color	Black, Red
Detachable stand	Yes
Front bezel color	Black/Red
Market positioning	Gaming
NVIDIA G-SYNC	No
AMD FreeSync type	FreeSync Premium
AMD FreeSync refresh rate range	48 - 165 Hz
Panel type	VA
Pixel pitch	0.3114 x 0.3114 mm
Aspect ratio	4:3, 16:9
Screen shape	Flat
Pixel density	81 ppi
Backlight type	W-LED
Display surface	Matt
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Adobe RGB coverage	98 %
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	48 - 144 Hz
Horizontal scan range	30 - 160 kHz
Supported video modes	1080p
NTSC coverage (typical)	102 %
sRGB coverage (typical)	122 %
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.6 cm
Viewable size, horizontal	597.888 mm
Display brightness (typical)	350 cd/m²
HDMI version	1.4
DisplayPort version	1.2
Headphone connectivity	3.5 mm
Package type	Box
Package depth	187 mm
Package width	730 mm
Package height	520 mm
Package weight	6960 g
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	45 W
Power consumption (off)	0.3 W
Power consumption (typical)	26 W
Tilt angle range	-5 - 23 °
Cable lock slot type	Kensington
Number of OSD languages	19
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
RMS rated power	2 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Cables included	DisplayPort, HDMI
DisplayPort cable length	1.8 m
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	227.4 mm
Width (with stand)	612.5 mm
Height (with stand)	464.6 mm
Weight (with stand)	4630 g
Depth (without stand)	48.8 mm
Height (without stand)	365.8 mm
