9
Connecting the Monitor
Cable Connections In Back of Monitor :
1. Microphone out (Connect to PC)
2. Microphone in
3. Earphone (Combined with Microphone)
4. Quick Switch port
5. DP
6. HDMI1
7. HDMI2
8. USB C
9. USB3.2 Gen1 upstream
10. USB3.2 Gen1 downstream + fast chargingx1
USB3.2 Gen1 downstreamx1
11. USB3.2 Gen1 downstreamx2
12. Power
13. Power Switch
Connect to PC
1. Connect the power cord to the back of the display rmly.
2. Turn o your computer and unplug its power cable.
3. Connect the display signal cable to the video connector of your computer.
4. Plug the power cord of your computer and your display into a nearby outlet.
5. Turn on your computer and display.
If your monitor displays an image, installation is complete. If it does not display an image, please refer Troubleshooting.
To protect equipment, always turn o the PC and LCD monitor before connecting.
