Service Manual AOC2241VG
17
5.3 Power Board Block Diagram
Fuse
EMI
Rectifier
Smoothing
Capacitor
C907
Transformer
T901
MOS
Q901
IC-PWM
IC901
16V
Rectifier
5V
Rectifier
16V
5V
Sense
resistor
Vcc
Rectifier
regulating
Sampling
PhotoCoupler
Vcc
Open Lamp Protection
16V DC
5V
DIM
DC-AC
Transformer
T801
High Voltage
Output
Resonance NET
Switching MOS
Q805-Q806
AO4620
AC input
100-240V
2- CCFL
PWM Control IC
IC801-TA9687
Current Sampling
Power part
Inverter part
Power/ inverter Board Block Diagram
