AOC AOC2241VG User Manual

Service Manual AOC2241VG
47
10.BOM List
Note: The parts information listed below are for reference only, and are subject to change
without notice. Please go to http://cs.tpv.com.cn/hello1.asp for the latest information.
10.1 Model：TC9GNTNBWVK2HNJ
Location
Part number
Description
Remark
040G 581 26704 SHIPPING LABEL
2nd source
040G 581689 4A BARCODE LABEL FOR 1 3
052G 1209 A 200MINIUM TAPE 2
052G 1211 A
Conductive Tape 55mm *45mm *0.08mm (
单导）
1
052G 1211 B
Conductive Tape 85mm *40mm *0.09mm (
单导
)
1
070GHDCP500HDC NO-SUGGEST HDCP CODE 2
E08905 089G 175 8 G FQE41177F USB CABLE 1800mm A+B
2nd source
E08905 089G 175 8 H USB CABLE A+B 1.8M 1
E08902 089G 725CAADBD D-SUB CABLE 1500MM
2nd source
E08902 089G 725GAADBD D-SUB CABLE 1500MM
2nd source
E08902 089G 725HAADBD D-SUB CABLE 1500MM 1
E08902 089G 725LAADBD D-SUB CABLE 1500MM
2nd source
E08907 089G179J30N576 FFC CABLE 1
E08901 089G404A15N HL AC POWER CORD 1500mm 1
E08901 089G404A15N IS POWER CORD I-SHENG
2nd source
E09503 095G8014 5DH15 HARNESS 5P(2008)-5P(2008) 300mm
2nd source
E09503 095G8014 5XH15 Wire harness 5P(2008)-5P(2008) 440MM 1
E09502 095G8014 6DH84 HARNESS 6P(2008)-6P(A1253HA HR) 360MM
2nd source
E09502 095G8014 6WH84 HARNESS 6P(2008)-6P(A1253HA HR) 360MM 1
0M1G 130 6120 SCREW M3X6 4
XN01A 0M1G1030 6120 SCREW M3X6 3
XN01B 0M1G1030 6120 SCREW M3X6 1
XN01C 0M1G1030 6120 SCREW M3X6 1
0Q1G1030 6120 SCREW 1
0Q1G1030 8120 SCREW 4
750GLG220W1P13N000 PANEL LM220WE1-TLP1 GZ LGD 1
756GJ9CB AK009 MCU ASS'Y MIAN BOARD CBPC9NTA1QYJ
U402 056G1133 90 1 IC PM25LV020-100SCE 2MB SOIC-8 PMC
2nd source
U402 056G2233 11 IC Pm25LD020C-SCE SIOC-8(150mil) 2M
2nd source
SMTCR-U402 100GANGC003B11 AOC_2241Vg_LGLM220WE1_NT68668_100422_001
AM1G1740 12 47 CR3 SCREW 1
AM1G1740 12120 SCREW 3
CBPC9NTA1QYJ MIAN BOARD 1
CN402 033G3802 6B Y CONN 6PIN 2.0
2nd source
CN402 033G3802 6B Y L WAFER 1
CN701 033G3802 9B Y CONNECTOR 9P 2.0
2nd source
CN701 033G3802 9B Y L CONN 2.0 9P 1
CN408 033G801930F CH JS CONNECTOR 1
040G 45762412B CBPC LABEL 1
CN101 088G 35315F HD D-SUB CONN F ATTACHED SCREW 1
CN102 088G 35424F D DVI 24PIN CONN F ATTACHED SCREW
2nd source
CN102 088G 35424F XH DVI 24PIN CONN F ATTACHED SCREW 1
X401 093G 2251B J CRYSTAL 12MHZ NXS12.000AC30F-KAB10 1
AIG9NTA1QYJ MAIN BOARD FOR AI 1
C716 067G 3051007PB EC 10UF 20% 50V 5*11 1

AOC AOC2241VG Specifications

General

Brand	AOC
Model	AOC2241VG
Category	Monitor
Language	English
