Service Manual AOC2241VG
48
C433 067G 4051013PB EC 100uF M 16V 5*11mm 1
C705 067G 4051013PB EC 100uF M 16V 5*11mm 1
C702 067G 4051013PB EC 100uF M 16V 5*11mm 1
SMTC9NTA1QYJ MAIN BOARD FOR SMT 1
U401 056G 562327 IC Scaler NT68668AFG QFP-128 1
U701 056G 563224 IC LDO AP2114H-3.3TRG1 1A/3.3V SOT-223 1
U106 056G 662504 IC ESD AOZ8902CIL 24KV 5A SOT23-6 AOS 1
U107 056G 662504 IC ESD AOZ8902CIL 24KV 5A SOT23-6 AOS 1
U104 056G 662504 IC ESD AOZ8902CIL 24KV 5A SOT23-6 AOS 1
U103 056G 662504 IC ESD AOZ8902CIL 24KV 5A SOT23-6 AOS 1
U102 056G 662504 IC ESD AOZ8902CIL 24KV 5A SOT23-6 AOS 1
U101 056G1133 34 M24C02-WMN6TP 1
U105 056G1133 34 M24C02-WMN6TP 1
U402 056G1133 90 1 IC PM25LV020-100SCE 2MB SOIC-8 PMC
2nd source
U402 056G2233 11 IC Pm25LD020C-SCE SIOC-8(150mil) 2M 1
Q701 057G 417 12 T KEC 2N3904S-RTK/PS
2nd source
Q706 057G 417 12 T KEC 2N3904S-RTK/PS
2nd source
Q401 057G 417 13 T KEC 2N3906S-RTK/PS
2nd source
Q402 057G 417 13 T KEC 2N3906S-RTK/PS
2nd source
Q701 057G 417511 MMBT3904 1
Q706 057G 417511 MMBT3904 1
Q402 057G 417512 MMBT3906 1
Q401 057G 417512 MMBT3906 1
Q401 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
2nd source
Q402 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
2nd source
Q701 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
2nd source
Q706 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
2nd source
Q705 057G 763940 MOSFET AO3401A SOT-23 1
R103 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA
2nd source
R104 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA
2nd source
R109 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA
2nd source
R110 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA
2nd source
R117 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA
2nd source
R118 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA
2nd source
R406 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA
2nd source
R407 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA
2nd source
R711 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN 1
R410 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN 1
R409 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN 1
R407 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN 1
R406 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN 1
R118 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN 1
R117 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN 1
R110 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN 1
R109 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN 1
R104 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN 1
R103 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN 1
R141 061G0402100 JF RST CHIPR 10 OHM +-5% 1/16W FENGHUA
2nd source
R140 061G0402100 JF RST CHIPR 10 OHM +-5% 1/16W FENGHUA
2nd source
R139 061G0402100 JF RST CHIPR 10 OHM +-5% 1/16W FENGHUA
2nd source
