1. LCD Specifications
1.1 Product Features
Monitor Model AOC2241VG
LCD Panel
Driving system TFT Color LCD
Active Display Area
558.67mm（21.995inch） diagpnal
473.76mm (W)×296.15mm(H)
Pixel Pitch 0.282 mm×0.282mm
Display Colors 16.7M Colors
Max. Resolution 1680 x 1050@60Hz
Input
Video
R,G,B Analog Interface，75ohm,0.7V
DVI digital Interface, 150mV-1200mV
Separate Sync. H/V TTL
H-Frequency 30kHz—81kHz
V-Frequency 56Hz--75Hz
Dot Clock 165MHz
Plug & Play VESA DDC2B /CI
Connector
D-Sub 15pin
DVI -D 24pin
USB HUB
1 upstream, 1 downstream 2.0
Power Consumption
ON Mode <35W
Power Saving Mode <0.5W
Switch OFF
<0.1W
Power Source
90~264VAC,47~63Hz, 1.5A Max supply current
Dimensions(including stand)
522.3mm×413.3mm×186.8mm
Weight (N. W.): 5.15kg
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp.: -20° to 60°C
Operating Humidity : 8% to 80%
Altitude:
Operating ：0~ 3000m (0~ 10000 ft )
Non-Operating：0~ 5000m (0~ 15000 ft )
Safety
FCC B CCC IEC950CB etc.

AOC AOC2241VG Specifications

General

Brand	AOC
Model	AOC2241VG
Category	Monitor
Language	English
