Service Manual AOC2241VG

55

R004 061G0603200 1F RST CHIPR 2 KOHM +-1% 1/10W 1

LED01 081G 14501 GP LED GPTD1210YGC3-HB 1

E715 715G4007K01000004F KEY PCB FR-4 106.5X14.5MM T1.6MM

2nd source

E715 715G4007K01000004L KEY PCB FR-4 106.5X14.5MM T1.6MM 1

PWPCC21GA1J POWER G2892-P02-016-001C-X-2-100414 1

GND1 009G6005 1 GROUND TERMINAL 1

CN801 033G8021 2E F CONNECTOR

2nd source

CN803 033G8021 2E F CONNECTOR

2nd source

CN803 033G8021 2E XY CONNECTOR 1

CN801 033G8021 2E XY CONNECTOR 1

040G 45762412B CBPC LABEL 2

IC902 056G 139 3A PC123Y22FZOF SHARP 1

IC902 056G 139900 PHOTO COUPLER TLP421F

2nd source

NR901 061G 58100 X NTC10D2-14MC 1

NR901 061G 58100 WD RST NTCR 10 OHM +-20% 5A THINKING

2nd source

C908 063G107K334 6S 0.33UF +-10%

2nd source

C908 063G107K334 US NO-SUGGEST 0.33UF 275VAC+-10% EUROP 1

C817 065G 6J2096ET 2PF 5% SL 6KV 1

C903 065G305M1022BP CAP Y2 1000PF M 250VAC 1

C902 065G305M1022BP CAP Y2 1000PF M 250VAC 1

C900 065G306M3322BP Y1 CAP 3300PF M 250VAC 1

C925 067G215D4714KV EC 105C CAP 470uF M 25V

2nd source

C925 067G215D4714LV LOW ESR EC 470uF 25V M 10*16mm

2nd source

C804 067G215P1024XV CAP 105C 1000UF M 25V 1

C918 067G215P1024XV CAP 105C 1000UF M 25V 1

C925 067G215P4714XV CAP 105C 470UF M 25V 1

C804 067G215S1024KV EC 1000UF 20% 25V 12.5*20

2nd source

C918 067G215S1024KV EC 1000UF 20% 25V 12.5*20

2nd source

C804 067G215S1024LV LOW ESR EC 1000uF 25V M 12.5*20mm

2nd source

C918 067G215S1024LV LOW ESR EC 1000uF 25V M 12.5*20mm

2nd source

C922 067G215S4713KV

EC 105℃ CAP 470UF M 16V

2nd source

C922 067G215S4713LV LOW ESR EC 470uF 16V M 10*12.5mm 1

C922 067G215V471 3H CAP L105C 470UF M 16V

2nd source

C922 067G215V471 3N EC 470UF 16V NCC KY16VB470-M-L 10*12.5mm

2nd source

C907 067G315Z10115K EC 100UF 20% 450V 18*40 1

C907 067G315Z10115L EC 100uF 450V M 18*40mm

2nd source

L901 073G 174 65 H2 LINE FILTER 30mH MIN

2nd source

L901 073G 174 65 S2 LINE FILTER 30mH MIN 1

L906 073G 253 91 H IND CHOKE 3.5uH+-10% DADONG 1

L905 073G 253 91 H IND CHOKE 3.5uH+-10% DADONG 1

L905 073G 253 91 L CHOKE BY LI TA

2nd source

L906 073G 253 91 L CHOKE BY LI TA

2nd source

T901 080GL22T 3 N1 X'FMR 490uH YUVA-1093 1

T901 080GL22T 3 S1 X'FMR 490uH

2nd source

PT801 080GL24T 23 DN X'FMR 68uH TK.2005Y.101 VOC

2nd source

CN901 087G 501 32 S AC SOCKET ST-01CP-BCE-R 1

CN901 087G 501 32 DL AC SOCKET DIP 3PIN+2PIN GROUND

2nd source

BD901 093G 50460 28 BRIDGE DIODE KBP208G LITEON 1

BD901 093G 50460502 BRIDGE KBP206G C2

2nd source

BD901 093G 50460514 BRIDGE KBP306G-05 3A/800V TSC

2nd source
