23
Specification
General Specification
Panel
Model name CQ32G3SE
Driving system TFT Color LCD
Viewable Image Size
80
cm diagonal
Pixel pitch 0.
2724
mm(H) x 0.
2724
mm(V)
Video HDMI lnterface & DP Interface
Separate Sync. H/V TTL
Display Color 16.7M Colors
Others
Horizontal scan range 30k-
25
0kHz
Horizontal scan Size(Maximum)
697.344
mm
Vertical scan range 48-
16
5Hz
Vertical Scan Size(Maximum)
392.256
mm
Optimal preset resolution 2560x1440@60Hz
Max resolution
2560x1440@144Hz(HDMI)
2560x1440@165Hz(DP)
Plug & Play VESA DDC2B/CI
Power Source 100-240V~, 50/60Hz, 1.5A
Power Consumption
Typical(default brightness and contrast)
52
W
Max. (brightness = 100, contrast =100) ≤
68
W
Standby mode ≤0.3W
Physical
Characteristics
Connector Type HDMI/DP/Earphone out
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AOC CQ32G3SE and is the answer not in the manual?

AOC CQ32G3SE Specifications

General IconGeneral
Panel typeVA
Color gamut93 %
Pixel pitch0.2724 x 0.2724 mm
Backlight typeW-LED
Display diagonal31.5 \
Surface hardness3H
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Adobe RGB coverage91 %
Display technologyLCD
Native aspect ratio16:9
NTSC coverage (typical)102 %
Screen curvature rating1000R
Viewable size, vertical392.256 mm
sRGB coverage (typical)123 %
Contrast ratio (dynamic)80000000:1
Contrast ratio (typical)3000:1
Display number of colors16.7 million colors
Display diagonal (metric)80.01 cm
Viewable size, horizontal697.344 mm
Display brightness (typical)250 cd/m²
High Dynamic Range (HDR) supportedYes
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10)
RMS rated power5 W
Number of speakers2
Feet colorBlack/Red
Product colorBlack, Red
Market positioningGaming
DisplayPort version1.4
Headphone connectivity3.5 mm
USB Type-A downstream ports quantity4
Tilt angle range3.5 - 21.5 °
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
Input current1.5 A
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.3 W
Power consumption (typical)52 W
HDMI cable length1.8 m
Sustainability certificatesWEEE
Exterior finish typeTextured
Package weight10520 g
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)263.8 mm
Width (with stand)700.5 mm
Height (with stand)523.7 mm
Weight (with stand)7020 g
Depth (without stand)111.2 mm
Height (without stand)424.2 mm
Weight (without stand)6290 g
