4.3 Panel Specification
4.3.1 General Features
M200FGE-L23 is a 20.0” TFT Liquid Crystal Display module with WLED Backlight unit and 30 pins 2ch-LVDS
interface. This module supports 1600(H) x 900(V),HD+ resolution and can display up to 16.7M colors. The converter
module for Backlight is not built in.
4.3.2 GENERAL SPECIFICATIONS
4.3.3 Electrical Characteristics
1.TFT LCD Module
2.BACKLIGHT UNIT
Note :
(1) Permanent damage to the device may occur if maximum values are exceeded. Function operation should be
restricted to the conditions described under Normal Operating Conditions.
(2) Specified values are for input pin of LED light bar at Ta=25±2 _ (Refer to 4.3.3 and 4.3.4 for further information).
