AOC E2050SN - 2 LCD Monitor Description

5
2.LCD Monitor Description
The LCD MONITOR will contain a main board, a power board, and a key board which house the flat panel control
logic, brightness control logic and DDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips
each voltage.
Monitor Block Diagram
HOST Computer
AC-IN
100V-240V
Power Board
Flat Panel and
LED backlight
Main Board
RS232 Connector
For white balance
adjustment in factory
mode
LED Driver
Video signal DDC
Keyboard
