AOC e2460Swd Service Manual

Service Manual E2460Swd
51
CN404
033G3802 6B Y
CONN 6PIN 2.0
1
CN404
033G3802 6B Y L
WAFER
1
CN701
033G3802 9B Y
CONNECTOR 9P 2.0
1
CN701
033G3802 9B Y L
CONN 2.0 9P
1
CN410
033G801930F CH B
FFC CONN 1.0mm 30P R/A 34mm 6mm
1
CN410
033G801930F CH L
FFC CONN 1.0mm 30P R/A 34mm 6mm
1
CN410
033G801930F CH JS
FFC CONN 1.0mm 30P R/A 34mm 6.3mm
1
CN101
088G 35315F HD
D-SUB CONN 15P BLUE - R/A
1
CN101
088G 35315F XH
D-SUB 15PIN VERTICAL CONN WITH SCREW
1
CN102
088G 35424FXNH
DVI CONN WITH SCREW 24P R/A
1
X401
093G 22 53 J
CRYSTAL 14.31818MHZ/32PF49US
1
CN102
388G354GOF2YDL
DVI CONN R/A 24P WHITE H=10.25MM
1
709G52700ZM001
COMSUMPTIVE ASSY
1
052G 2191 A
PAPER TAPE
0.02
Q49G 51100
cleaner
0.11
Q55G 23525
WELDING FLUX WITHOUT PB
0.85
Q55G 100620500
TIN STICK(Sn-0.5Ag)
1.71
Q55G 100622
TIN STICK(SAC0507)
0.006
AIGBB7A1ZA
MAIN BOARD FOR AI
1
C430
067G 3051013PB
EC 105C 100uF M 16V 5*11mm JH CD263
1
C702
067G 3051013PB
EC 105C 100uF M 16V 5*11mm JH CD263
1
C705
067G 3051013PB
EC 105C 100uF M 16V 5*11mm JH CD263
1
709G52700ZA001
COMSUMPTIVE ASSY
1
052G 2191 A
PAPER TAPE
0.16
SMTCBB7A1ZA
MAIN BOARD FOR SMT
1
040G 45762420A
LABEL 25x6mm
0.09
U401
056G 562A22
SCALER TSUMU58VHN-1 LQFP-80
1
U701
056G 585 4A
LDO AP1117E33G-13 1A 3.3V SOT-223
1
U106
056G 662 52
ESD PROTECT AZC398-04S.R7G SOT23-6
1
U101
056G 662 52
ESD PROTECT AZC398-04S.R7G SOT23-6
1
U103
056G 662 52
ESD PROTECT AZC398-04S.R7G SOT23-6
1
U107
056G 662 52
ESD PROTECT AZC398-04S.R7G SOT23-6
1
U104
056G 662 52
ESD PROTECT AZC398-04S.R7G SOT23-6
1
U105
056G1133 34 1
EEPROM M24C02-RMN6TP 2Kb SO-8
1
U102
056G1133 34 1
EEPROM M24C02-RMN6TP 2Kb SO-8
1
U402
056G2233 11
FLASH Pm25LD020C-SCE 2M SIOC-8
1
U402
056G2233501
FLASH MX25L2026DM1I-12G 2Mb SOP-8
1
Q401
057G 417517
Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
1
Q403
057G 417517
Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
1
Q706
057G 417518
TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
1
