AOC e2460Swd - Page 59

Service Manual E2460Swd
59
D101
393G006404200P00HF
HF BAV70_R1_00001 0.5A 100V SOT-23
1
709G52700ZS001
COMSUMPTIVE ASSY
1
052G 2191 A
PAPER TAPE
0.1
052G6026 2
MESH PRINTTING_PAPER
0.43
055G 23520
IPA
0.7
055G 100610
TIN CREAM W/O PB
0.354
Q05G6054 1
SHEET
0.03
Q09G6012 1
PIN
0.008
E715
715G5270M01000004C
MAIN PCB FR4 DS 80X72+1.6(mm)
1
E715
715G5270M01000004L
MAIN PCB FR4 DS 80*72*1.6mm
1
H40G 45762429A
LABEL
1
KEPCCZA5
KEY BOARD
1
LED001
381G00122YG0GP
LED yellow/green GP32032M/P310-ZY-30
1
CN001
395G820H06DM04
HARNESS 6P-6P 320mm
1
CN001
395G820H06XM04
HARNESS 6P-6P 320mm
1
709G53570ZM001
COMSUMPTIVE ASSY
1
055G 23524
WELDING FLUX WITHOUT PB
0.56
Q49G 51100
cleaner
0.09
Q55G 100622
TIN STICK(SAC0507)
0.003
Q55G 100650500
Solder Stick
0.382
SMTKEPCCZA5
KEY BOARD FOR SMT
1
R001
061G0603101 JI
RST 0603 100R 5% 1/10W TA-I
1
R003
061G0603101 JI
RST 0603 100R 5% 1/10W TA-I
1
R003
061G0603101 JY
RST CHIPR 100 OHM +-5% 1/10W YAGEO
1
R001
061G0603101 JY
RST CHIPR 100 OHM +-5% 1/10W YAGEO
1
R002
061G0603102 JI
TEST ONLY RST 0603 1K 5% 1/10W TA-I
1
R002
061G0603102 JT
RST CHIP 1K 1/10W 5% TZAI YUAN
1
R005
061G0603202 JI
RST 0603 2K 5% 1/16W TA-I
1
R004
061G0603202 JI
RST 0603 2K 5% 1/16W TA-I
1
R004
061G0603202 JT
RST 0603 2K 5% 1/10W
1
R005
061G0603202 JT
RST 0603 2K 5% 1/10W
1
ZD007
093G 64 59 SU
ESD MLVS0603M04 0603
1
ZD001
093G 64 59 SU
ESD MLVS0603M04 0603
1
ZD005
093G 64 59 SU
ESD MLVS0603M04 0603
1
ZD003
093G 64 59 SU
ESD MLVS0603M04 0603
1
ZD004
093G 64 59 SU
ESD MLVS0603M04 0603
1
ZD002
093G 64 59 SU
ESD MLVS0603M04 0603
1
ZD006
093G 64 59 SU
ESD MLVS0603M04 0603
1
709G53570ZS001
COMSUMPTIVE ASSY
1
Q05G6054 1
SHEET
0.003
