AOC E950SW User Manual

49
Troubleshoot
Problem & Question
Possible Solutions
Power LED Is Not ON
Make sure the power button is ON and the Power Cord is properly connected
to a grounded power outlet and to the monitor.
No images on the screen
Is the power cord connected properly?
Check the power cord connection and power supply.
Is the cable connected correctly?
(Connected using the D-sub cable)
Check the DB-15 cable connection.
(Connected using the DVI cable)
Check the DVI cable connection.
* DVI input is not available on every model.
If the power is on, reboot the computer to see the initial screen (the login
screen), which can be seen.
If the initial screen (the login screen) appears, boot the computer in the
applicable mode (the safe mode for Windows ME/XP/2000) and then change
the frequency of the video card.
(Refer to the Setting the Optimal Resolution)
If the initial screen (the login screen) does not appear, contact the Service
Center or your dealer.
Can you see "Input Not Supported" on the screen?
You can see this message when the signal from the video card exceeds the
maximum resolution and frequency that the monitor can handle properly.
Adjust the maximum resolution and frequency that the monitor can handle
properly.
Make sure the AOC Monitor Drivers are installed.
Picture Is Fuzzy & Has
Ghosting Shadowing Problem
Adjust the Contrast and Brightness Controls.
Press to auto adjust.
Make sure you are not using an extension cable or switch box. We
recommend plugging the monitor directly to the video card output connector
on the back .
Picture Bounces, Flickers Or
Wave Pattern Appears In The
Move electrical devices that may cause electrical interference as far away
from the monitor as possible.
Use the maximum refresh rate your monitor is capable of at the resolution
your are using.

AOC E950SW Specifications

General

3D	No
Aspect ratio	16:10
Display diagonal	19 \
Display resolution	1366 x 768 pixels
Viewable size diagonal	470 mm
Viewable size, vertical	230.4 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	409.8 mm
Viewing angle, horizontal	170 °
Digital vertical frequency	50 - 75 Hz
Digital horizontal frequency	30 - 60 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1366 x 768
Power requirements	90-240VAC
Ethernet LAN (RJ-45) ports	0
Certification	CCC, CEPC, cCSAus, CE, FCC, EPA, TUV-S, ISO9241-307, TCO5.1, BSMI, China RoHs, Win7, TCO5.1
Product color	Black
Market positioning	-
Tilt angle range	-4 - 17 °
Number of OSD languages	16
On Screen Display (OSD)	Yes
Panel mounting interface	75 x 75 mm
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	15 W
Package depth	110 mm
Package width	496 mm
Package height	356 mm
Package weight	3550 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	175 mm
Width (with stand)	444.35 mm
Height (with stand)	342 mm
Width (without stand)	- mm
Weight (without stand)	2630 g
