AOC F19S Service Manual

53
R480 061G152M22964L SY RST MOFR 2.2 OHM +-5% 2WS FUTABA
CN101 088G 35315F HD D-SUB CONN F ATTACHED SCREW
X401 093G 22 53 YC Crystal 14.31818MHz/32PF 49U/S YC
CN405 311GW200C30ABL WAFER 2.0mm 2*15P
709G3244 HM002 CONSUMPTIVE ASS'Y
CN001 033G3802 6B YH W WAFER
SW005 077G 603 3 TO TACT SWITCH TS-03-BS
SW004 077G 603 3 TO TACT SWITCH TS-03-BS
SW002 077G 603 3 TO TACT SWITCH TS-03-BS
SW001 077G 603 3 TO TACT SWITCH TS-03-BS
SW003 077G610D 1 CJ TACT SW+LED 6P 7.2 - 3642501
CN802 033G8021 2E F CONNECTOR
CN801 033G8021 2E F CONNECTOR
040G 45762412B CBPC LABEL
IC902 056G 139 9 IC EL817M(X) photocoupler DIP-4
NR901 061G 58080 N RST NTCR 8OHM SHAGON
R908 061G152M10452T SY RST MOFR 100KOHM +-5% 2WS FUTABA
C904 063G107K224AUM CAP X2 0.22uF 10% 305V
C908 063G107K224AUM CAP X2 0.22uF 10% 305V
C801 065G 3J3006ET NO-SUGGEST 30PF 5% SL 3KV TDK
C803 065G 3J3006ET NO-SUGGEST 30PF 5% SL 3KV TDK
C901 065G305M1022BP CAP Y2 1000PF M 250VAC
C902 065G305M1022BP CAP Y2 1000PF M 250VAC
C900 065G306M3322BP Y1 CAP 3300PF M 250VAC
C907 067G 40Z82015K EC 82uF M 450V 18*35mm
C802 067G215D4714KV EC 105C CAP 470uF M 25V
C940 067G215P1023XV EC 1000UF 20% 16V 10*20
C922 067G215P4714AV CAP 105C 470UF M 25V
C918 067G215P6814AV CAP 105C 680UF M 25V
C917 067G215P6814AV CAP 105C 680UF M 25V
C915 067G215S4713KV
EC 105℃ CAP 470UF M 16V
L904 073G 253 91 V1 CHOKE COIL 1.1uH
L903 073G 253 91 V1 CHOKE COIL 1.1uH
L901 073L 174 40 HG LINE FILTER 30.0mH MIN
CN901 087G 501 32 S AC SOCKET ST-01CP-BCE-R
D905 093G 60519 DIODE SR560-MK23 5A/60V DO-27 SECOS
CN902 095G 82510TE12 HARNESS 10P-9P 120MM
705GQ857020 Q901 ASS'Y
705GQ893028 D906 ASS'Y
709G2852 HM001 CONSUMPTIVE ASS'Y
PW9821MHD3SMT POWER BOARD FOR SMT
T801 S80GL17T40V transformer
T901 S80GL19T26V Transformer ASS'Y
BD901 093G 50460 28 BRIDGE DIODE KBP208G LITEON
055G 2 ALCOHOL
055G 23524 WELDING FLUX WITHOUT PB
Q55G 100625 TIN STICK_LOW ARGENTUM
C427 067G 3051014PT EC 100UF 20% 25V 6.3*11
C421 067G 3051014PT EC 100UF 20% 25V 6.3*11
C423 067G 3051014PT EC 100UF 20% 25V 6.3*11
709G3244 HA002 CONSUMPTIVE ASS'Y
