AOC F19S Service Manual

54
U401 056G 562266 IC Scaler RTD2270S-GR LQFP-64
U404 056G 563 52 IC AP1117D33G-13 TO252-3L DIODES
U102 056G 662502 IC ESD AZC199-04S.R7G SOT23-6L
U103 056G 662502 IC ESD AZC199-04S.R7G SOT23-6L
U405 056G1133531 EEPROM FM24C02A-SO-T-G 2K SOP-8
U402 056G2233501 FLASH MX25L2026DM1I-12G 2Mb SOP-8
Q406 057G 417 12 T KEC 2N3904S-RTK/PS
Q409 057G 417 16 T MMBT2907
Q410 057G 417 16 T MMBT2907
Q402 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q403 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q404 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q407 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q405 057G 763 1 AO3401 SOT23 BY AOS
R481 061G0402000 JY NO-SUGGEST RST CHIPR MAX 0R05 OHM 1/16W
R462 061G0402000 JY NO-SUGGEST RST CHIPR MAX 0R05 OHM 1/16W
R461 061G0402000 JY NO-SUGGEST RST CHIPR MAX 0R05 OHM 1/16W
R402 061G0402000 JY NO-SUGGEST RST CHIPR MAX 0R05 OHM 1/16W
R442 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R420 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R413 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R412 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R411 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R405 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R401 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R117 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R102 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R103 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R104 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R108 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R111 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R114 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R115 061G0402101 JY NO-SUGGEST RST CHIPR 100 OHM +-5% 1/16W
R441 061G0402102 JY NO-SUGGEST RST CHIPR 1KOHM +-5% 1/16W YA
R439 061G0402103 JY NO-SUGGEST RST CHIPR 10KOHM +-5% 1/16W Y
R437 061G0402103 JY NO-SUGGEST RST CHIPR 10KOHM +-5% 1/16W Y
R433 061G0402103 JY NO-SUGGEST RST CHIPR 10KOHM +-5% 1/16W Y
R421 061G0402103 JY NO-SUGGEST RST CHIPR 10KOHM +-5% 1/16W Y
R414 061G0402103 JY NO-SUGGEST RST CHIPR 10KOHM +-5% 1/16W Y
R410 061G0402103 JY NO-SUGGEST RST CHIPR 10KOHM +-5% 1/16W Y
R408 061G0402103 JY NO-SUGGEST RST CHIPR 10KOHM +-5% 1/16W Y
R407 061G0402103 JY NO-SUGGEST RST CHIPR 10KOHM +-5% 1/16W Y
R404 061G0402103 JY NO-SUGGEST RST CHIPR 10KOHM +-5% 1/16W Y
R118 061G0402103 JY NO-SUGGEST RST CHIPR 10KOHM +-5% 1/16W Y
R436 061G0402104 JY RST CHIPR 100KOHM +-5% 1/16W YAGEO
R469 061G0402222 JY RST CHIPR 2.2KOHM +-5% 1/16W YAGEO
R466 061G0402222 JY RST CHIPR 2.2KOHM +-5% 1/16W YAGEO
R106 061G0402222 JY RST CHIPR 2.2KOHM +-5% 1/16W YAGEO
R105 061G0402222 JY RST CHIPR 2.2KOHM +-5% 1/16W YAGEO
R109 061G04023900FY RST CHIP 390R 1/16W 1%
R403 061G04023900FY RST CHIP 390R 1/16W 1%
