OSD Setting
Basic and simple instruction on the control keys.
1) Press the MENU-button to activate the OSD window.
2) Press < or > to navigate through the functions. Once the desired function is highlighted, press the
MENU-button to activate it . press < or > to navigate through the sub-menu functions. Once the desired
function is highlighted, press MENU-button to activate it.
3) Press < or > to change the settings of the selected function. Press AUTO to exit. If you want to adjust
any other function, repeat steps 2-3.
4) OSD Lock Function: To lock the OSD, press and hold the MENU button while the monitor is off and then
press power button to turn the monitor on. To un-lock the OSD - press and hold the MENU button
while the monitor is off and then press power button to turn the monitor on.
Notes:
1) If the product has only one signal input, the item of "Input Select" is disable to adjust.
2) If the product screen size is 4:3 or input signal resolution is native resolution, no 4:3 and 1:1 display modes are
available for such key.
3) One of DCR, Color Boost, i-Care, DPS and Picture Boost functions is active, the other 4 function is turned off
accordingly.
20

Other manuals for AOC G2460PQU

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AOC G2460PQU and is the answer not in the manual?

AOC G2460PQU Specifications

General IconGeneral
3DNo
Panel typeTN
Color depth6 bit
Pixel pitch0.276 x 0.276 mm
Aspect ratio16:9
Product typePC monitor
Backlight typeW-LED
Pixel frequency330 MHz
Display diagonal23.6 \
Vertical scan range50 - 76 Hz
Horizontal scan range30 - 83 kHz
Viewable size, vertical298.89 mm
Viewing angle, vertical160 °
Contrast ratio (dynamic)80000000:1
Contrast ratio (typical)1000:1
Display number of colors16.78 million colors
Viewable size, horizontal531.36 mm
Viewing angle, horizontal170 °
Display brightness (typical)350 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
AC adapter includedYes
Mean time between failures (MTBF)50000 h
HDMI version1.4
USB hub version2.0
DisplayPort version1.1
Component video (YPbPr/YCbCr) in0
USB Type-A downstream ports quantity4
Tilt angle range-5 - 22 °
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
Thin client installed-
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0.22 W
Power consumption (standby)0.31 W
Power consumption (typical)22.7 W
CertificationISO
Product colorBlack
Market positioningGaming
Package weight8550 g
Cables includedAudio (3.5mm), DVI, USB, VGA
Doesn't containBRF, PVC
Sustainability certificatesRoHS, EPEAT Gold, ENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth (without stand)52.95 mm
Width (without stand)565.4 mm
Height (without stand)342.9 mm
Weight (without stand)6540 g
