AOC G2590VXQ User Manual

How to clean the monitor?
Turn off the monitor first. Gently wipe away any dust on the computer monitor using a very soft cloth. Wipe the
flat screen as softly as possible, starting at one side and swiping straight across. Do not rub the flat screen in a
circular or up and down motion, as this could scratch the flat screen. Do not try to wipe away any streaks, spots
or grime with
the dry cloth either. The purpose of this step is simply to wipe off as much dust as possible.
When you are done dusting, moisten a special cleaning cloth or tool, or another clean, soft cloth with special
liquid cleaner for flat screens, distilled water, or a mixture of white vinegar and distilled water. Do not spray or
pour any type of cleaner directly onto the computer monitor. Doing so could cause the liquid to drip down inside
of the flat screen, causing irreparable damage. Instead, spray the cleaner onto the cloth or dip the cloth into the
liquid. Again, try not to press too hard on the flat screen as you clean it. Pressing into the screen can cause
permanent damage. Wipe the dampened cloth gently from side to side or from top to bottom. Make sure the
computer monitor is com
pletely dry before you turn it back on.
When the liquid drips down/ gets accumulated near the sides/ corners, it causes the metal frame of the LCD
panel to corrode thereby causing gaps through which air rushes inside the two glass plates inside the panel.
This makes crystals of the LCD (Liquid Crystal Display – Crystals with some electric properties floating in a
liquid medium) to dislocate and appear to us as air bubbles (or black spots as commonly called) inside the
panel. Such defects are not covered under the standard warranty.
Our services haven’t met your expectations? Share your feedback to our Service Head
If we haven’t been able to meet your expectations or you would like share a feedback or suggestion to our
Service Head, please write an email to
india@aoc-support.com. If your feedback is related to a service
request, please mention the 12 digit Service Job Number in your email.
62

AOC G2590VXQ Specifications

General

3D	-
Panel type	TN
Color depth	8 bit
Pixel pitch	0.2832 x 0.2832 mm
Screen shape	Flat
Backlight type	W-LED
Display surface	Matt
Pixel frequency	165 MHz
Display diagonal	24.5 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	30 - 76 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	302.62 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	543.74 mm
Viewing angle, horizontal	170 °
Digital vertical frequency	- Hz
Digital horizontal frequency	- kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDMI version	1.4
DisplayPort version	1.2
Headphone connectivity	3.5 mm
RMS rated power	4 W
Cables included	AC, Audio (3.5mm), DisplayPort, HDMI, VGA
HDMI cable length	1.8 m
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Pivot angle	1 - 90 °
Tilt angle range	-3.5 - 21.5 °
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AMD FreeSync type	FreeSync
AMD FreeSync refresh rate range	30 - 75 Hz
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Certification	ISO
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Gaming
Package type	Box
Package depth	173 mm
Package width	627 mm
Package height	417 mm
Package weight	6620 g
Sustainability certificates	RoHS
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	179.5 mm
Height (with stand)	419.8 mm
Weight (with stand)	4300 g
Depth (without stand)	78.2 mm
Width (without stand)	558.6 mm
Height (without stand)	- mm
Weight (without stand)	- g
