19
5. Using an audio cable (red and white connectors), connect the
cable to the audio output connectors associated with the
Component output on your TV Set-Top Box and connect the
other end to the audio connectors associated with the
Component.
6. Turn on the power to the TV and TV Set-Top Box.
7. Select Component using the INPUT button on the remote, side
of the TV or directly by pressing the COMP button on the
Remote Control.
Connecting Your Basic Set-Top Box
Using Composite Video
1. Turn off the power to the TV and Set-Top Box.
2. Using an AV Cable, connect the Video (yellow color) connector
on your Set-Top Box to the corresponding Video (yellow color)
connector in the AV group at the rear of the TV.
3. Using the red and white connectors, connect the cable to the
audio output connectors associated with the Video output on
your Set-Top Box and connect the other end to the audio
connectors associated with the AV input at the rear of the TV.
4. Turn on the power to the TV and Set-Top Box.
5. Select Composite using the INPUT button on the remote, side
of the TV or directly by pressing the VIDEO button on the
Remote Control.
Note:
Refer to your TV Set-Top Box user manual for more information
about the video output requirements of the product or consult
our cable or satellite o
erato
.
ENGLISH
