3.2 Compatible Mode Table

Analog RGB Input Signal Timing

No Resolution H-freq.(kHz) V-freq. (Hz) Pixel clock (MHz) Mode

1 640x480 31.469 59.940 25.175 VGA

2 640x480 37.861 72.809 31.500 VGA

3 640x480 37.500 75.000 31.500 VGA

4 720x400 31.469 70.087 28.322 VGA

5 800x600 35.156 56.250 36.000 SVGA

6 800x600 37.879 60.317 40.000 SVGA

7 800x600 48.077 72.188 50.000 SVGA

8 800x600 46.875 75.000 49.500 SVGA

9 1024x768 48.363 60.004 65.000 XGA

10 1024x768 56.476 70.069 75.000 XGA

11 1024x768 60.023 75.029 78.750 XGA

12 1280x768 47.776 59.870 79.500 WXGA

13 1360x768 47.712 60.015 85.500 WXGA

14 1280x1024 63.981 60.020 108.000 SXGA

Only for LC42D1322
