HDMI Input Signal Timing
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock (MHz) Mode
1 720*480 15.734 60 27 SDTV 480I
2 720*480 31.5 60 27.00/27.03 SDTV 480P
3 720*576 15.625 50 27 SDTV 576I
4 720*576 31.25 50 54 SDTV 576P
5 1280*720 37.5 50 74.25 HDTV 720P
6 1280*720 44.96 / 45 59.94 / 60 74.17/74.25 HDTV 720P
7 1920*1080 33.72 / 33.75 59.94 / 60 74.17/74.25 HDTV 1080I
8 1920*1080 28.125 50 74.25 HDTV 1080I
9 1920*1080 26.97/27 23.97/24 74.17/74.25 HDTV 1080P
10 1920*1080 26.98 25 74.25 HDTV 1080P
11 1920*1080 33.716/33.75 29.976/30.00 74.25 HDTV 1080P
12 1920*1080 56.25 50 148.5 HDTV 1080P
13 1920*1080 67.43/67.5 59.94/60 148.35/148.50 HDTV 1080P
