AOC LE22H138 User Manual

31
Dimensions & Specifications
Model LE22H138 LE24H138
Panel Size 546mm(21.5”) 609.7mm(24.0”)
Resolution 1920 x 1080 1920 x 1080
TV System NTSC standard
PAL-M & PAL-N
NTSC standard
PAL-M & PAL-N
Channel coverage Air: 2 through 69
Cable TV: 1 through 125
Air: 2 through 69
Cable TV: 1 through 125
Speaker 3W x 2 3W x 2
Antenna impedance 75Ω 75Ω
Power source 100-240V ~ 50/60Hz, 2.0A 100-240V ~ 50/60Hz, 2.0A
Standby power consumption <1W <1W
Video/Audio Terminals Side AV x1: Video/Audio
Input/Audio output.
Side AV x1: Video/Audio
Input/Audio output.
Video/Audio Input VIDEO: 1 V(p-p), 75 ohm, negative
sync.
AUDIO: 500mv (rms)
VIDEO: 1 V(p-p), 75 ohm, negative
sync.
AUDIO: 500mv (rms)
Video/Audio Output VIDEO: 1 V(p-p), 75 ohm, negative
sync.
AUDIO: 500mv (rms)
VIDEO: 1 V(p-p), 75 ohm, negative
sync.
AUDIO: 500mv (rms)
Component Input Rear Component x1:
Y: 1V(p-p), 75 ohm, including sync.
Pr/Cr: ±0.35V(p-p), 75 ohm
Pb/Cb: ±0.35V(p-p), 75 ohm
AUDIO: 500mv (rms)
Rear Component x1:
Y: 1V(p-p), 75 ohm, including sync.
Pr/Cr: ±0.35V(p-p), 75 ohm
Pb/Cb: ±0.35V(p-p), 75 ohm
AUDIO: 500mv (rms)
HDMI Terminals HDMI INPUT: Rear HDMI x1;
HDCP compliant
E-EDID compliant
HDMI INPUT: Rear HDMI x1;
HDCP compliant
E-EDID compliant
VGA Terminals VGA INPUT:
Rear VGA (D-SUB 15 Pin) Input x1
E-EDID compliant
Audio Input: Mini-jack for stereo
(3.5ø)
VGA INPUT:
Rear VGA (D-SUB 15 Pin) Input x1
E-EDID compliant
Audio Input: Mini-jack for stereo
(3.5ø)
Headphone Audio Output: Mini-jack for stereo
(3.5 ø)
Audio Output: Mini-jack for stereo
(3.5 ø)
Size (W x H x D) (with base and
stand)(mm)
525 x 351 x 101.8 584.36 x 378.79 x 125.69
Weight 4.31Kg (with stand) /
3.31Kg(w/o stand and base)
5.53kg(with stand) /
4.22Kg(w/o stand and base)
Wall mount size 100 x 100 mm (Wall mount kit is
not included)
75 x 75 mm (Wall mount kit is
not included)
Wall-Mount accessory Optional accessory and not
included in standard package
Optional accessory and not
included in standard package
Operating Temperature
conditions Humidity
0
o
C to +40
10%~85%
To 3,000m
o
C
Note:
_ Designs and specifications are subject to change without notice.
_ This model may not be compatible with features and/or specifications that may be added in the future.
English
Size (W x H x D) (without base
and stand)(mm)
525 x 341.13 x 37.7 584.36 x 371.62 x 37.7
SPDIF Output Coaxial Digital Audio Out jack Coaxial Digital Audio Out jack
Altitude
Storage Temperature
condition Humidity
-10
o
C to +50
5%~85%
To 10,000m
o
C
Altitude
0
o
C to +40
10%~85%
To 3,000m
o
C
-10
o
C to +50
5%~85%
To 10,000m
o
C
