7. Adjustment
White balance adjustment:
1. press "menu +1+9+9+9+ back" into the factory mode;
2. Adjust Ypbpr source for this model, take YPBPR Mode “NORMAL” for example;
3. Use remote control to choose “Current Source”, select Ypbpr, Color temp and then choose NORMAL;
4. Adjust the R/G/B value, the temperature adjustment to the required specification range,
(Ypbpr TIM 314，PAT 141);
5. Luminance required specification range MAX LV>160.
White balance value checking: check AV、HDMI、VGA source color temperature, confirm it’s within the
specification, if white balance value is not within the specification, adjust the source again as the steps
described above .
Adjustment specifications are written in the white balance program, test to product specification shall prevail:
Warm Normal Cool
x (center)
0.313 0.030 0.295 0.030 0.285 0.030
y (center)
0.329 0.030 0.305 0.030 0.293 0.030
