AOC LE24D1331/30 User Manual

49
11. BOM List
Note: The following information of initial version BOM are only for reference of repair, not place the order as the
basis and are subject to change without notice. Please base on RSPL or Service BOM (http://cs.tpv.com.cn), thank
you!
LE19D1331/30 E1BC21NSAPE8NNX
Location Part No. Description Remark
089G 17356C554 AUDIO CABLE 1800MM
E08901 089G202A15N IS AC POWER CORD 1500MM
398GRABD7NEACR REMOTE AOC RC2414704/01 ENGLISH
Q11T5024 1 GP WIRE-CLIP
M04501 Q45G99010TV04900X1 PROTECT BAG
M05201 Q52G18010TV0500AJY INSULATING SHEET
X33T0052ADTZ1L0100 KEY_FUNCTION
X41G22MV67304B MANUAL LE19_22_24D1331
092GB1JX1A3EGC BATTERY 1.5V LR03 AAA£¨LR03£© ALKALI
ECN701 395G801313XM73 HARNESS 13P-13P 100
M01101 Q11G701017000L00ZL PCB-SUPPORT PA66 YES 94V-V0
M04501 Q45G99010TV04900ZW PROTECT BAG
M05201 Q52G18010TV0500AZA INSULATING SHEET
X40G019061509A RATING LABEL --LE19D1331/30
0Q1G 940 18 47 CR3 SCREW
X15T860110100000BL BKT_SPEAKER
ECN401 395G801410XY67 HARNESS 10P(1253)-5P+4P 200/320
X15T863330100000YF BKT_KEY
IRPFCXE4 IR BOARD
CN201 033G8032 5F S HR CONNECTOR
R201 061G0402153 JT RST CHIP 15K 1/16W 5% TZAI YUAN
R203 061G0402221 JF RST CHIPR 220 OHM £«-5£¥ 1/16W FENGHUA
C201 065G0603225A5K M CAP MLCC 0603 2.2UF K 10V X5R
LED201 081G 15 3 GP CHIP LED BLUE/RED GPTD12048BRC1-AR
U201 356GS927038006 SMD IR RECEIVER TSOP75438TR 38
E715 715G5889R01000004S IR BOARD PCB
X15T8612201000GMBL BKT_IO
0Q1G 930 12 47 CR3 SCREW 01-SPECIAL SCREW X12
ECN601 395G801304DN04 HARNESS 4P-2P+2P 60/230
0M1G 940 16 47 CR3 SCREW M1-MACHINE SCREW X16
X33T0021 GM 1G0100 COVER_CLOCK_REAR
Q12G6300 26 6 SILICONE GASKET
M03601 Q36G 600 35 3 TS NON-WOVEN FABRIC CLOTH 0.3 0.3
Z40G0002ALL01A SFIS LABEL 35MM*9MM
CN466 033G3802 3B Y WAFER 2.0MM 3P V/T 7.95MM 5.1MM
CN602 088G302C5B1ACL PHONE JACK R/A 5P BLACK H=6.2
CN602 088G302C5B1AQS PHONE JACK R/A 5P 1*1 BLACK 6.2MM.
CN103 088G352F6B3ACL USB A TYPE R/A 6P BLACK H=8.4
CN101 088G353FFF1XCL HF HF D-SUB CONN SCREWED V/T 15P BLUE H=8.6
CN111 388G078F233XQS RCA V/T 12P 2*3 G/B/R+W/R/Y 8.6MM
CN111 388G078F233XYG RCA V/T 12P 2*3 G/B/R+W/R/Y 8.4MM
CN102 388G302F4O3VQS PHONE JACK V/T 4P 1*1 ORANGE 15.5
TU101 394GATSCALL12G TUNER LATAM TDST-H030F
709T57490XM001 COMSUMPTIVE ASSY
Z40G0002ALL01A SFIS LABEL 35MM*9MM
055G 23520 IPA
055G 23524 WELDING FLUX WITHOUT PB
Q49G 51100 CLEANER
