9.4 Key Board
715G5795K01000004S
R1 4.7K 1%
1
2
3
4
65
CN01
CONN
SARADC
R2 750R 1% R3 820R 1% R4 1.2K 1%
33G8032 4F HR
R5 1.8K 1%
R7 2.7K 1% R8 5.6K 1%
+3.3V
R9 13K 1/16W 1%
Source MENU VOL- VOL+Power CH+CH-
SW01
TACT SW FWRD H1.5MM
SW2
TACT SW FWRD H1.5MM
SW3
TACT SW FWRD H1.5MM
SW4
TACT SW FWRD H1.5MM
SW5
TACT SW FWRD H1.5MM
SW6
TACT SW FWRD H1.5MM
SW7
TACT SW FWRD H1.5MM
OEM MODEL Size
Rev
Date
Sheet of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹 B
A
22Friday , June 29, 2012
<
称爹 >
02-Keypad
0V 0.45V 0.83V 1.63V1.22V 2.42V2.0V
