AOC LE24D1331/30 User Manual

58
X15T861310100000BL BKT_POWER_TOP
SP01 378G0035566YAH 16 OHM 3.5W L100XW27 100 NO
X15T819210100000BL BKT_VESA SGCC
ECN403 395G801840XY38 LVDS CABLE 30P-40P 160
X15T823510200000YF BKT_POWER_L SGCC
X15T861120100000YF MAINFRAME
Q41G780061532G SHEET-FLYER SA CENTER LIST
X41G78DV61503C WARRANTY CARD SA ALL REGION
Q50G 500 TV005 CABLE TIE
X33T0051ADT01L0100 KEY_FUNCTION
X34T0101ADTZ1L0100 BEZEL
X40G0001624 2A LABEL FOR SCREW PE BAG
Q45G88010TV05800X1 PROTECT BAG
040G 58162435A MANUAL P/N LABEL
PLTVC9391UXA1 POWER BOARD
040G 45762412B OTHER LABEL
009G6005 1 GP GND TERMINAL
CN8102 033G8021 2E XY CONNECTOR
IC9102 056G 139 8
PHOTO-COUPLER PS2561DL1-1 CTR
Q100~200%
IC9102 056G 139 3A PC123Y22FZOF SHARP
NR9901 061G 58159LAW 5A NTCR 1.5R 15% 2.4W SCK101R55LMY502
NR9902 061G 58159LAW 5A NTCR 1.5R 15% 2.4W SCK101R55LMY502
R9130 061G153M47159B SY RST MOF 470R 5% 3W
C9901 063G107M474AUM CAP X2 470NF 20% 305V
FB9908 071G 55906 FERRITE CORE 510R C8B R6H 6X9.2(A)
FB9902 071G 55906 FERRITE CORE 510R C8B R6H 6X9.2(A)
L9901 073G 174192 H LINE FILTER 30MH MIN LCL-12012 HA
L9901 073G 174192 X LINE FILTER 30MH MIN ET20 0.8A
L9101 073G 253 91 H IND CHOKE 3.5UH+-10% DADONG
L9102 073G 253 91 H IND CHOKE 3.5UH+-10% DADONG
L9102 073G 253 91 V CHOKE COIL 3.5UH+-10%
L9101 073G 253 91 V CHOKE COIL 3.5UH+-10%
L8102 073G 253214 H CHOKE COIL 47UH 10% L470R HA
L8102 073G 253214 X CHOKE COIL 47UH 10% ,HF
T9101 080GL32P 92 YS X'FMR 800UH 10% 20UH EFD30 YS04160400
CN9901 087G 50147C DL AC SOCKET V/T 2P ACT1MD-02BL4B006 H=14
BD9101 093G 50460 50 BRIDGE GBL08 4A/800V GBL
D8101 093G 60520 DIODE SR5100-MK23 5A/100V DO-27 SECOS
D8101 093G 60924 DIODE SR510-22 DO-201AD
0Q1G 340 8140 SCREW Q1-SELF TAPING SCREW :Q X8.0
CN9101 311GW250B13BBX WAFER 2.5MM 13P R/A 35MM 7MM
RV9901 361G0046621KZW VARISTOR 620V 10%
C9102 367G215X470PKZ002S EC 47UF 20% 450V 12.5*36 2000 HR 420MA P
C9101 367G215X470PKZ002S EC 47UF 20% 450V 12.5*36 2000 HR 420MA P
BD9101 393G0050460A03 BRIDGE GBL408-C 4A 800V GBL 150A
BD9101 393G0050460A05 BRIDGE GBL08-07 X0 4A 800V GBL
705TXC57995
705 组件
Q9101 057G 667931 MOSFET AOTF8N65 8A 650V TO-220FP
0M1G1730 8120 SCREW 3X8
Q9101 357G0667A11 MOSFET STF6N65K3 5.4A 650V 30W TO-220FP
HS3 Q90G0219 4 HEAT SINK ÐͲÄ/PROFILE
705TXC84023
705 组件
084G 34 14 FUSE -- -- --
