14
3. Input / Output Specification
D-Sub and HDMI Pin assignment
DͲSub(CN101) HDMI1(CN501) HDMI2(CN506)
PINNo. Signal PIN
No.
Signal PIN
No.
Signal
1 Red 1 TMDS Data2+ 1 TMDS Data2+
2 Green 2 TMDS Data2 shield 2 TMDS Data2 shield
3 Blue 3 TDMS Data2- 3 TDMS Data2-
4
D/TXDC
4 TMDS Data1+ 4 TMDS Data1+
5 GND 5 TMDS Data1 shield 5 TMDS Data1 shield
6 RedGND 6 TMDS Data1- 6 TMDS Data1-
7 GreenGND 7 TMDS Data0+ 7 TMDS Data0+
8 BlueGND 8 TMDS Data0 shield 8 TMDS Data0 shield
9 +5V(supplyfromPC) 9 TMDS Data0- 9 TMDS Data0-
10 SyncGND 10 TMDS Clock+ 10 TMDS Clock+
11
D/RXDC
11 TMDS Clock Shield 11 TMDS Clock Shield
12 BiͲdirectional data
(SDA)
12 TMDS Clock- 12 TMDS Clock-
13 HͲsync 13 CEC 13 CEC
14
Ͳsync(vclk) 14 ARC 14 NC
15 Dataclock(SCL) 15 SCL 15 SCL
16 SDA 16 SDA
17 DDC_Ground 17 DDC_Ground
18 +5V Power 18 +5V Power
19 Hot Plug Detect 19 Hot Plug Detect
20 SHLD_GND1
21 SHLD_GND2
