AOC LE24D3140_30

31
7. Adjustment
They only need adjust WB(Ypbpr’s Normal/Warm/Cool).
7.1 White Balance Adjustment
1. Enter into the factory mode:MENU+1+9+9+9+back
2. Take an example of adjust Ypbpr_Normal:
a. Select item “Source”: Ypbpr
and item “Color Temp”: Normal.
b. Adjust gain of RGB to meet spec in the below setting of tim\pat.
(COMPONENT mode: TIM = 314; PAT = 141(80IRE))
3. Check the colour temperature of other ĀSourceāˈ
If the colour temperature can’t meet specˈplease adjust it
4.The white color temperature should be app.
Normal/(9300
q
K) Warm/(6500
q
K) Cool/(12000
q
K)
x (center) 0.295 r 0.003 0.313 r 0.003 0.285 r 0.003
y (center) 0.305 r 0.003 0.329 r 0.003 0.293 r 0.003
Lv(center) >240cd >240cd >240cd
