8. Block Diagram
With ARC
YPbPr CVBS
DTV DEMOD MSB1400
Single terminal silicon tuner (LG TDST-H030F)
Series TS
Analog IF+/-
RGB
Headphone AMP
LVDS
AUDIO AMP
APA2176A
L/R
5W SPK 5W SPK
R L
R
emote Control
KeyPad
AV Audio
USB
L/R
ATV DEMOD
UART
TI 31100
MST6931XP
Headphone
