Service Manual AOCn941Splus
47
10.BOM List
Note: The parts information listed below are for reference only, and are subject to change
without notice. Please go to http://cs.tpv.com.cn/hello1.asp
for the latest information.
10.1 Model：T99ANSNYWVA1NNJ
Location Part number Description Remark
040G 58160811A GREEN DOT LABEL 1
040G 58162461A EPA LABEL 1
040G 581689 4A BARCODE LABEL FOR 1 2
052G 1211 A Tasma aluminiowa 1
052G 1211 B
Conductive Tape 85mm *40mm *0.09mm (单导)
2
E08902 089G 725GAA DB D-SUB CABLE 1500mm 1
E08902 089G 725HAA DB D-SUB CABLE
2nd source
E08907 089G179J30N521 FFC CABLE 30Pin P1.0 210mm
2nd source
E08901 089G414A15N HL POWER CORD 1500MM China Reg 1
E08901 089G414A15N IS POWER CORD 1500MM China Reg
2nd source
E09508 095G8014 6DH52 HARNESS 6P(PLUG)-6P(A1253HA HR) 260
2nd source
E09508 095G8014 6WH52 HARNESS 6P(PLUG)-6P(A1253HA HR) 260 1
0M1G 130 5120 SCREW 4
0M1G1030 6120 SCREW 3x6 1
0M1G1030 6120 SCREW 3x6 3
E750 750GAU190W1707N000 LCD M190PW01 V700 WJ AUO
2nd source
E750 750GAU190W17A7N000 LCD M190PW01 V70A WJ AUO 1
756GJ9CB AA082 MCU ASSY
U402 056G1133 90 1 IC PM25LV020-100SCE 2MB SOIC-8 PMC
2nd source
U402 056G2233 11 IC Pm25LD020C-SCE SIOC-8(150mil) 2M
2nd source
SMTCR-U402 100GANA9000B21 AOCN941S_NT68168_AUOM190PW01V7_V002
AM1G1740 12 47 CR3 SCREW 1
AM1G1740 12 47 CR3 SCREW 3
CBPC9NWA1QHJ CONVERSION G3225-1-2-X-23-100512 1
CN406 033G3802 6B Y CONN 6PIN 2.0
2nd source
CN406 033G3802 6B Y L WAFER 1
CN404 033G3802 9B Y CONNECTOR 9P 2.0
2nd source
CN404 033G3802 9B Y L CONN 2.0 9P 1
CN403 033G801930F CH L FFC CONN 1.0mm 30P R/A 34mm 6mm 1
CN403 033G801930F CH JS FFC CONN 1.0mm 30P R/A 34mm 6.3mm
2nd source
CN101 088G 35315F HJ D-SUB 15PIN CONNECTOR SBFR151-U02-NP
2nd source
CN101 088G 35315F XH D-SUB 15PIN VERTICAL CONN WITH SCREW 1
X401 093G 2251B J CRYSTAL 12MHZ NXS12.000AC30F-KAB10 1
AIG9NWA1QHJ MAIN BOARD FOR AI 1
C704 067G 4051014PT EC 100uF M 25V 6.3*11mm JF CD287 1
C702 067G 4051014PT EC 100uF M 25V 6.3*11mm JF CD287 1
C449 067G 4051014PT EC 100uF M 25V 6.3*11mm JF CD287 1
SMTC9NWA1QHJ MAIN BOARD FOR SMT 1
040G 45762420A LABEL 25x6mm 1
U401 056G 562325 SCALER NT68168AFG LQFP-64 1
U701 056G 563 47 IC AME8815BEGT330Z SOT-223 BY AME
2nd source
U701 056G 563224 LDO AP2114H-3.3TRG1 1A 3.3V SOT-223 1
U102 056G 662 48 ESD PROTECT AZC399-04S.R7G SOT23-6L 1
U103 056G 662 48 ESD PROTECT AZC399-04S.R7G SOT23-6L 1
U101 056G1133 34 EEPROM M24C02-WMN6TP 2Kb SO-8 1
