Service Manual AOCn941Splus
7
2. Operation instruction
2.1 Connection
Connect the video cable from the video card of PC to the monitor.
The power cord should be connected.
Press the power button to turn on the monitor, the power indicator will light up.
2.2 Control Buttons
Control Description
1
Power Button
To turn ON/OFF the moniteor, and power indicator (Green/Blue
and Amber/Orange).
2
Menu / Enter
Active main menu while no OSD display,enter next level on main
menu or sub menu status, or enter last level on adjustment bar..
Hotkey ,exit
3
4:3 or wide/ +
Hotkey,Audio volume adjust for VA ,or chang 4:3 or wide image ratio
for SA .
OSD, increase current value of bar, or move to next item of menu
4
ECO mode(DCR)/ -
If there is no OSD,select the ECO mode of brightness and DCR.
OSD, it will decrease current value of bar, or it will move to last
item of menu.
5
Auto / Exit
If there is no any OSD, select video source(DVI/RGB).
Press hold to 2s , it is auto configuration.
Exit current OSD and return to last level.
