Specification
General Specification
Panel
Model Name Q24G2A/BK
Driving System TFT Color LCD
Viewable Image Size 60.4cm Diagonal
Pixel Pitch
0.2055(H) x 0.2055(V)
Others
Horizontal Scan Range
30k-230kHz(HDMI)
30k-250kHz(DP)
Horizontal Scan Size(Maximum) 526.08 mm
Vertical Scan Range
48-144Hz(HDMI)
48-165Hz(DP)
Vertical Scan Size(Maximum) 295.92 mm
Max Resolution
2560x1440@144Hz(HDMI)
2560x1440@165Hz(DP)
Plug & Play VESA DDC2B/CI
Power Source 100-240V~, 50/60Hz,1.5A
Power Consumption
Typical (Default Brightness and Contrast) 34W
Max. (Brightness = 100, Contrast = 100) ≤54W
Standby Mode ≤0.3W
Physical
Characteristics
Connector Type HDMI/DP/Earphone Out
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°C~ 40°C
Non-Operating -25°C~ 55°C
Humidity
Operating 10% ~ 85% (Non-Condensing)
Non-Operating 5% ~ 93% (Non-Condensing)
Altitude
Operating 0 ~ 5000m (0 ~ 16404ft)
Non-Operating 0 ~ 12192m (0 ~ 40000ft)
