21
Specification
General Specification
Panel
Model name Q2790PQ
Driving system TFT Color LCD
Viewable Image Size 68.6cm diagonal
Pixel pitch
0.2331mm(H) x 0.2331mm(V)
Separate Sync. H/V TTL
Display Color 16.7M Colors
Others
Horizontal scan range 30~99KHz
Horizontal scan Size(Maximum) 596.736mm
Vertical scan range
50Hz~76Hz
Vertical Scan Size(Maximum) 335.664mm
Optimal preset resolution 1920x1080@60Hz(VGA)
Max resolution 2560x1440@60Hz(HDMI, DP)
Plug & Play VESA DDC2B/CI
Power Source 100-240V~,50/60Hz
Power Consumption
Typical(default brightness and contrast) 33W
Max. (brightness = 100, contrast =100) ≤ 48W
Standby mode <0.5W
Physical
Characteristics
Connector Type D-Sub/ HDMI/DP/Earphone out
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )
