AOC Q2790PQE User Manual

10
Adjusting
Hotkeys
1
2 4
5
3
1 Source/Auto/Exit
2 Clear Vision
3 ECO
4 Image ratio / Volume
5 Menu/Enter/ Power
Up/Source/Auto/Exit
When the OSD is closed, press “up” button will be Source hot key function. When the OSD is closed,
press “up” button continuously about 2 second to do auto congure (Only for the models with D-Sub).
Image Ratio/Volume/Right
When there is no OSD, press the “right” key to open the volume adjustment bar
,
under the HDMI / DP source.
When there is no OSD, press the “right” key to enter the image scale switching function, under the D-SUB signal source
(If the product screen size is wide format, the hot key is disable to adjust).
Down/ECO
When there is no OSD, press “down” to active ECO adjustment bar, press left or right to adjust ECO mode.
Power/Menu/Enter
Press the Power button to turn on the monitor.
When there is no OSD, Press to display the OSD or conrm the selection. Press about 2 second to turn o󰀨 the
monitor

AOC Q2790PQE Specifications

General

Pixel pitch	0.233 x 0.233 mm
Screen shape	Flat
Backlight type	W-LED
Pixel frequency	170 MHz
Display diagonal	27 \
Surface hardness	3H
Adobe RGB coverage	92 %
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
NTSC coverage (typical)	85 %
Viewable size, vertical	336.31 mm
sRGB coverage (typical)	125 %
Contrast ratio (dynamic)	100000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.6 cm
Viewable size, horizontal	597.88 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	2560 x 1440
Pivot	Yes
Tilt angle range	-5 - 21 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
Certification	True
Product color	Black
Front bezel color	Gray
Heavy metals free	Hg (mercury)
Market positioning	Business
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	40 W
Sustainability certificates	RoHS
Package depth	226 mm
Package width	703 mm
Package height	468 mm
Package weight	9900 g
VGA cable length	1.8 m
Exterior finish type	Textured
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Cables included	DisplayPort, HDMI, VGA
Compatibility	VESA-P1
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	199.5 mm
Width (with stand)	614.9 mm
Height (with stand)	535 mm
Weight (with stand)	6200 g
Depth (without stand)	43.5 mm
Height (without stand)	364.1 mm
Weight (without stand)	4400 g
