AOC Q27B3MA User Manual

23
Specification
General Specification
Panel
Model name Q27B3MA
Driving system TFT Color LCD
Viewable Image Size 68.5 cm diagonal
Pixel pitch
0.2331mm(H) x 0.2331mm(V)
Display Color 16.7M Colors
Others
Horizontal scan range 30k-114kHz
Horizontal scan Size(Maximum) 596.736mm
Vertical scan range 48-75Hz
Vertical Scan Size(Maximum)
335.664mm
Optimal preset resolution 2560x1440@60Hz
Max resolution 2560x1440@75Hz
Plug & Play VESA DDC2B/CI
Power Source 100-240V~, 50/60Hz, 1.5A
Power Consumption
Typical(default brightness and contrast) 25W
Max. (brightness = 100, contrast =100)
≤
35W
Standby mode
≤
0.3W
Physical
Characteristics
Connector Type HDMI/DP/Earphone out
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )

AOC Q27B3MA Specifications

General

Panel type	VA
Pixel pitch	0.2331 x 0.2331 mm
Screen shape	Flat
Pixel density	108.8 ppi
Backlight type	W-LED
Display diagonal	27 \
Surface hardness	6H
Anti-glare screen	Yes
Adobe RGB coverage	95 %
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
NTSC coverage (typical)	96 %
sRGB coverage (typical)	110 %
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	4000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.6 cm
Display brightness (typical)	250 cd/m²
AMD FreeSync	-
Brand-specific features	False
Certification	True
Front bezel color	Black
Market positioning	Home
Exterior finish type	Matt
Ethernet LAN (RJ-45) ports	0
Mean time between failures (MTBF)	50000 h
RMS rated power	4 W
Number of speakers	2
Tilt angle range	-3.5 - 21.5 °
Cable lock slot type	Kensington
Number of OSD languages	19
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
HDMI version	1.4
Headphone outputs	1
DisplayPort version	1.2
Headphone connectivity	3.5 mm
Cables included	AC
HDMI cable length	1.5 m
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Socket connector type	C5
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Package type	Box
Package depth	142 mm
Package width	690 mm
Package height	453 mm
Package weight	6390 g

Weight and Dimensions

Depth (with stand)	229.8 mm
Width (with stand)	614 mm
Height (with stand)	460 mm
Weight (with stand)	3900 g
Depth (without stand)	44.7 mm
Height (without stand)	363.8 mm
