AOC Q27G4X User Manual

18
HDR
Off
Set the HDR prole according to your usage requirements.
Note:
When HDR is detected, the HDR option is displayed for
adjustment.
DisplayHDR
HDR Picture
HDR Movie
HDR Game
HDR Mode
Off
Optimized for the color and contrast of the picture, which will
simulate showing the HDR effect.
Note:
When HDR is not detected, the HDR Mode option is displayed for
adjustment.
HDR Picture
HDR Movie
HDR Game
DCR
Off Disable dynamic contrast ratio.
On Enable dynamic contrast ratio.
Color Space
Panel Native Standard color space panel.
sRGB
sRGB Color space.
LowBlue
Mode
Off
Decrease blue light wave by controlling color temperature.
Multimedia
Internet
Ofce
Reading
Image Ratio
Full / Aspect / 1:1 /
17” (4:3) / 19” (4:3) /
19” (5:4) / 19”W (16:10) /
21.5”W (16:9)/
22”W (16:10)/
23”W (16:9) /
23.6”W (16:9) /
24”W (16:9)
Select image ratio for display.
Note:
1). When “HDR” is enable, all the items except “HDR“ under “Picture” cannot be adjusted.
2). When “HDR Mode” is enable, all the items except “HDR Mode”, “Brightness”, “DCR” cannot be adjusted.
3). When the “Color Space” is set to sRGB, all the items except “Color Space”, “Brightness”, “DCR” cannot be
adjusted.
4). When the “Eco Adjustment” is set to Reading, “Color Temp.”, “Gaming Mode”, “Game Color”, “LowBlue
Mode”, “MBR”, “MBR Sync” cannot be adjusted.

AOC Q27G4X Specifications

General

Warranty period	3 year(s)
Haze rate	25 %
Color gamut	90 %
Pixel pitch	0.2331 x 0.2331 mm
Screen shape	Flat
Response time	0.5 ms
Backlight type	W-LED
Display diagonal	27 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 180 Hz
Maximum refresh rate	180 Hz
Horizontal scan range	30 - 280 kHz
Viewable size, vertical	335.664 mm
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	1000:1
Display number of colors	1.07 billion colors
Display diagonal (metric)	68.5 cm
Viewable size, horizontal	596.736 mm
Display brightness (typical)	450 cd/m²
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10), DisplayHDR 400
Input current	1.5 A
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50/60 Hz
Power consumption (max)	50 W
Power consumption (standby)	0.3 W
Power consumption (typical)	29 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Pivot angle	-90 - 90 °
Tilt angle range	-3 - 21 °
Height adjustment	130 mm
HDCP version	2.2
DisplayPort version	1.4
Cables included	AC, DisplayPort, HDMI
Product color	Black, Red
Front bezel color	Black
Market positioning	Gaming
Package type	Box
Package depth	162 mm
Package width	822 mm
Package height	481 mm
Package weight	8360 g

Weight and Dimensions

Depth (with stand)	207.7 mm
Width (with stand)	613.9 mm
Height (with stand)	516 mm
Weight (with stand)	5290 g
Depth (without stand)	51.3 mm
Height (without stand)	366.3 mm
Weight (without stand)	3420 g
