AOC Q27G4ZD - Specification; General Specification

28
Specification
General Specification
Panel
Model name Q27G4ZD
Driving system OLED
Viewable Image Size 67.3 cm diagonal
Pixel pitch 0.2292mm(H) x 0.2292mm(V)
Display Color 1.07B Colors
[1]
Others
Horizontal scan range
30k~230kHz(HDMI)
30k~360kHz(DisplayPort)
Horizontal scan
Size(Maximum)
590.42 mm
Verticalscan range
48~144Hz (HDMI)
48~240Hz (DisplayPort)
Vertical Scan Size(Maximum) 333.72 mm
Optimal preset resolution 2560 x 1440@60Hz
Max resolution
2560 x 1440@144Hz (HDMI)
2560 x 1440@240Hz (DisplayPort)
Plug & Play VESA DDC2B/CI
Power Source
100-240V~ 50/60Hz 2A
Power Consumption
Typical(default brightness and contrast) 78W
Max. (brightness = 100, contrast =100)
≤117W
Standby Mode
≤0.5W
Physical
Characteristics
Connector Type
USB UP/USB-Ax4 (include 1 fast charge)
HDMIx2/DisplayPort/Earphone
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°C~40°C
Non-Operating -25°C~55°C
Humidity
Operating 10%~85% (Non-Condensing)
Non-Operating 5%~93% (Non-Condensing)
Altitude
Operating 0m~5000m (0ft~16404ft)
Non-Operating 0m~12192m (0ft~40000ft)
Note:
[1]The maximum number of display colors supported by this product is 1.07 billion, and the setting conditions
are as follows (there may be differences due to the output limitation of some graphics cards)
(“V”:support, “\” :nonsupport):
HDMI2.0 DisplayPort1.4
YCbCr420
YCbCr422
YCbCr444 RGB
YCbCr420
YCbCr422
YCbCr444
RGB
2560x1440@240Hz 10bpc \ \ V V
2560x1440@240Hz 8bpc \ \ V V
2560x1440@200Hz 10bpc \ \ V V
2560x1440@200Hz 8bpc \ \ V V
2560x1440@165Hz 10bpc \ \ V V
2560x1440@165Hz 8bpc \ \ V V
2560x1440@144Hz 10bpc V \ V V
Signal Version
Color Format
State
Color Bit
