AOC Q27P2CA User Manual

22
Specification
General Specification
Panel
Model name Q27P2CA
Driving system TFT Color LCD
Viewable Image Size 68.5 cm diagonal
Pixel pitch
0.2331mm(H) x 0.2331mm(V)
Display Color 16.7M Colors
Others
Horizontal scan range 30k-114kHz
Horizontal scan Size(Maximum) 596.736mm
Vertical scan range 48-75Hz
Vertical Scan Size(Maximum)
335.664mm
Optimal preset resolution 2560x1440@60Hz
Max resolution 2560x1440@75Hz (HDMI,DP,USB C*)
Plug & Play VESA DDC2B/CI
Power Source 100-240V~, 50/60Hz, 2.0A
Power Consumption
Typical(default brightness and contrast) 37W
Max. (brightness = 100, contrast =100)
≤
160W
Power saving
≤
0.5W
Physical
Characteristics
Connector Type HDMI/DP/USB C/Earphone out/USB3.2 Gen1
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )
*: USB C (DP Alt) signal input, and when “USB” is set to “3.2Gen1”, the maximum resolution is 1920 x 1080@75Hz.

AOC Q27P2CA Specifications

General

HD type	2K Ultra HD
Color depth	8 bit
Pixel pitch	0.2331 x 0.2331 mm
Aspect ratio	4:3, 16:9
Screen shape	Flat
Pixel density	10879 ppi
Backlight type	W-LED
Display surface	Matt
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
NTSC coverage (typical)	92 %
Viewable size, vertical	335.664 mm
sRGB coverage (typical)	104 %
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.6 cm
Viewable size, horizontal	596.736 mm
Display brightness (typical)	300 cd/m²
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB Power Delivery up to	65 W
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Tilt angle range	-5 - 35 °
Height adjustment	150 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
Package type	Box
Package depth	160 mm
Package width	690 mm
Package height	595 mm
Package weight	8800 g
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	37 W
RMS rated power	2 W
Certification	ISO
Product color	Black
Market positioning	Business
Compatibility	VESA-P2
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Cables included	DisplayPort, HDMI
DisplayPort cable length	1.8 m
Exterior finish type	Textured
Harmonized System (HS) code	85285210
Sustainability certificates	WEEE

Weight and Dimensions

Depth (with stand)	200.1 mm
Width (with stand)	613.6 mm
Height (with stand)	544.5 mm
Weight (with stand)	6300 g
Depth (without stand)	51.1 mm
Height (without stand)	369.5 mm
Weight (without stand)	4570 g
