AOC Q3277PQU User Manual

12
System requirement
FreeSync function
1. FreeSync function is working with DisplayPort.
2. Compatible Graphics Card: Recommend list is as the below, also could be checked by visiting
www.AMD.com
• AMD Radeon R9 295X2
• AMD Radeon R9 290X
• AMD Radeon R9 290
• AMD Radeon R9 285
• AMD Radeon R7 260X
• AMD Radeon R7 260
Wall Mounting
Preparing to Install An Optional Wall Mounting Arm.
This monitor can be attached to a wall mounting arm you purchase separately. Disconnect power before this procedure.
Follow these steps:
1. Remove the base.
2. Follow the manufacturer's instructions to assemble the wall mounting arm.
3. Place the wall mounting arm onto the back of the monitor. Line up the holes of the arm with the holes in the back of
the monitor.
4. Insert the 4 screws into the holes and tighten.
5. Reconnect the cables. Refer to the user's manual that came with the optional wall mounting arm for instructions on
attaching it to the wall.
Noted : VESA mounting screw holes are not available for all models, please check with the dealer or ofcial department
of AOC.

AOC Q3277PQU Specifications

General

3D	No
Panel type	MVA
Color depth	8 bit
Pixel pitch	0.276 x 0.276 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	32 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 99 kHz
Supported video modes	1440p
Viewable size, vertical	399 mm
sRGB coverage (typical)	100 %
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	3000:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	708 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	2560 x 1440
HDCP	Yes
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB Type-A downstream ports quantity	4
RMS rated power	6 W
Number of speakers	2
Mean time between failures (MTBF)	50000 h
Certification	ISO
Product color	Black, Silver
Front bezel color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Tilt angle range	-5 - 24 °
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A+ to F
Annual energy consumption	73 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	50 W
Package type	Box
Package depth	248 mm
Package width	577 mm
Package height	858 mm
Package weight	15310 g
VGA cable length	1.8 m
Cables included	AC, Audio (3.5mm), DVI, DisplayPort, HDMI, VGA
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth (with stand)	171.2 mm
Height (with stand)	659 mm
Weight (with stand)	11550 g
Depth (without stand)	60.8 mm
Width (without stand)	741.88 mm
Height (without stand)	438.42 mm
Weight (without stand)	- g
