AOC Q32E2N User Manual

24
Specification
General Specification
Panel
Model name Q32E2N
Driving system TFT Color LCD
Viewable Image Size 80cm diagonal
Pixel pitch 0.2727(H)mm x 0.2727(V) mm
Video HDMI Interface & DP Interface
Separate Sync
H/V TTL
Display Color 1.07B Colors
Others
Horizontal scan range
30-114kHz
Horizontal scan Size(Maximum)
698.112mm
Vertical scan range
48-75Hz
Vertical Scan Size(Maximum)
392.688mm
Optimal preset resolution
2560x1440@60Hz
Max resolution 2560x1440@75Hz
Plug & Play VESA DDC2B/CI
Power Source 100-240V~, 50/60Hz
Power Consumption
Typical (default brightness and contrast) 40W
Max. (brightness = 100, contrast =100) ≤ 60W
Standby mode ≤0.3W
Physical
Characteristics
Connector Type DP/HDMI/Earphone out
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )

AOC Q32E2N Specifications

General

Certification	True
Product color	Black
Detachable stand	Yes
Heavy metals free	Hg (mercury)
Market positioning	Business
HDMI version	1.4
Built-in USB hub	No
DisplayPort version	1.2
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.3 W
Power consumption (typical)	42 W
Sustainability certificates	RoHS, ENERGY STAR
Color depth	10 bit
Aspect ratio	4:3, 16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	Matt
Display diagonal	31.5 \
Surface hardness	3H
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Adobe RGB coverage	77 %
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 114 kHz
Supported video modes	1080p, 1440p
NTSC coverage (typical)	72 %
Viewable size, vertical	393.12 mm
sRGB coverage (typical)	104 %
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	80.01 cm
Viewable size, horizontal	698.88 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440
RMS rated power	3 W
Number of speakers	2
Tilt angle range	-6.5 - 23.5 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
HDMI cable length	1.8 m
Package type	Box
Package depth	187 mm
Package width	831 mm
Package height	553 mm
Package weight	10200 g
Recyclable packaging material	100 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	248.77 mm
Height (with stand)	529.67 mm
Weight (with stand)	7420 g
Depth (without stand)	57.67 mm
Width (without stand)	730.19 mm
Height (without stand)	434.16 mm
Weight (without stand)	- g
