AOC Q32P2 User Manual

10
Wall Mounting
Preparing to Install An Optional Wall Mounting Arm.
2
3
4
5
This monitor can be attached to a wall mounting arm you purchase separately. Disconnect power before this procedure.
Follow these steps:
1. Remove the base.
2. Follow the manufacturer’s instructions to assemble the wall mounting arm.
3. Place the wall mounting arm onto the back of the monitor. Line up the holes of the arm with the holes in the back of the
monitor.
4. Insert the 4 screws into the holes and tighten.
5. Reconnect the cables. Refer to the user’s manual that came with the optional wall mounting arm for instructions on
attaching it to the wall.
Noted:
VESA mounting screw holes are not available for all models, please check with the dealer or ofcial department
of AOC.
* Display design may differ from those illustrated.
WARNING:
1. To avoid potential screen damage, such as panel peeling, ensure that the monitor does not tilt downward by more than
-5 degrees.
2. Do not press the screen while adjusting the angle of the monitor. Grasp only the bezel.

AOC Q32P2 Specifications

General

HD type	2K Ultra HD
Color depth	10 bit
Pixel pitch	0.2737 x 0.2737 mm
Aspect ratio	4:3, 16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	Matt
Display diagonal	31.5 \
Surface hardness	3H
Anti-glare screen	Yes
Adobe RGB coverage	75 %
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
Supported video modes	1080p, 1440p
NTSC coverage (typical)	72 %
Viewable size, vertical	392.688 mm
sRGB coverage (typical)	102 %
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	1000:1
Display number of colors	1.07 billion colors
Display diagonal (metric)	80.01 cm
Viewable size, horizontal	698.112 mm
Digital horizontal frequency	30 - 114 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440
Compatibility	VESA-P2
RMS rated power	3 W
Number of speakers	2
Certification	GOST
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Pivot angle	0 - 180 °
Tilt angle range	-5 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	35 W
Storage temperature (T-T)	-20 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Cables included	DisplayPort, HDMI
DisplayPort cable length	1.8 m
Package type	Box
Package depth	225 mm
Package width	835 mm
Package height	545 mm
Package weight	12300 g
Exterior finish type	Textured
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Harmonized System (HS) code	85285210
Sustainability certificates	WEEE

Weight and Dimensions

Depth (with stand)	275.1 mm
Width (with stand)	730.19 mm
Height (with stand)	650.65 mm
Weight (with stand)	9500 g
Depth (without stand)	57.67 mm
Height (without stand)	434.16 mm
