Note: This picture is for example only, it may not exactly be the same motherboard.
Note: If you do not match the CPU
socket Pin 1 and CPU cut edge well, it
ma
y
damage the CPU.
3. Press down the CPU socket lever and finish
CPU installation.
CPU cut edge
