Traditional Green PC suspend mode does not really turn off the system power supply, it uses external box modem to trigger MB
COM port and resume back to active.
Note: This picture is for example only, it may not exactly be the same motherboard.
Pin 1
Pin 1
Serial Port
(Modem Side)
Serial Port
(Motherboard Side)
