3-7-5. Detach screw and align the notch to
Insert mini card into the slot and fix with screw.
3-7-6. Install the antenna wire with the button
of the wireless LAN or TV-tuner Mini card .
3-7-7. Arrange the wire to avoid damaging the
wire. According the photo.
3-7-8. Caution: Arrange the wire or cable not
well. The MPI–SATA card will damage the
wire or cable .
