Panel and I/O Connector
Notice:
Please do not reverse the computer,
or else the computer will damage.
Kensington Lock hole
Line in
Line Out
S/PDIF Out
Wireless 802.11
Antenna hole
Power eSATA Port
*
USB2.0 Port
USB 2.0 Ports
(USB 3.0 Port for GP1-Plus)
RJ45 LAN Jack
Displayport Port
DVI Port
19V DC Jack
DVD Eject Button
Power Button
Slot In Optical
Device Drive
Microphone
Line Out/Speaker Out
USB 2.0 Ports
* Note:
Using power eSATA cable, only support 5V output.
