8
OPERATING PROCEDURES
A.INITIALPROCEDURES
1. Makesureallswitchesaredeactivated.
2. Attachexternal sensorprobestothe threepin socket (#6on controlpanel
guide) .
3. AttachtheTopHeaterpowercord( #11oncontrolpanelguide) totheTop
heaterpowerconnector (#13oncontrolpanelguide) .
4. AttachtheTopheatersensorcord (#12formthecontrolpanelguide) tothe
baseconnector (#14 fromthecontrolpanelguide) .
5. Attachthedevicetothemainpowersource.ItisrecommendedtouseNEMA
plugs and receptacles with ratings compliant to the machine specifications 
(seepage6) .
6. To turnthe unitON.Togglethemainpowerswitchto ONposition (#8on
controlpanelguide) .
B.OPERATIONTYPE(MODE)SELECTION
1. Followinitialprocedures, “A.INITIALPROCEDURES” .
2. The display would show “TYPE 0”, which means Type 0operation will be
used.Toselectbetweentypes0to2.Presstheincreaseordecreasebuttons 
(#3&#4ofcontrolpanelguide) .
3. To confirm selection and enter into operation mode using the selected
operationtype.Presstheselectionbutton (#2ofcontrolpanelguide) .
C.SOLDERIRONUNDEROPERATIONTYPE0and1
1. To set the desired solder iron temperature press the selection button
repeatedly until the top display shows “SEt” and themiddle display shows
“iron”. Thebottom display would showthecurrentsettemperatureofthe
solderironfollowedbyasuffix“F”.
9
OPERATING PROCEDURES
2. Presstheincreaseordecreasebuttontoadjustthesettemperaturelevel.The
settemperatureisadjustablefrom200to480C.
3. For the solder iron actual temperature display. Follow TYPE “0”
OPERATION number5 (seepage10) .
4. To temporarily turn off the solder iron. Simultaneously press both the
“Increase”and“decrease”button (#3 & #4 fromthecontrolpaneldisplay
seepage8) .Thebottomdisplaywillshow“OFF”indicatingthesolderironis
nowturnedoff.
D.TYPE“0”OPERATION
Thistypeofoperationutilizestheinternaltemperaturesensorstocontrolthe
heat.  Using this type frees up the three extra external temperature probes for
monitoring.Attachthethreeextratemperatureprobestoareasofinterestsuchas
thebottomoftheboardand/ornearthecomponenttoweworkedon.
1. To set the desired top heater temperature press the selection button
repeatedlyuntilthetopdisplayshows “TOP”andthemiddle displayshows
“SEt”.Thebottomdisplaywouldshowthecurrentsettemperatureofthetop
heaterfollowedbyasuffix“A”.
2. Press the increase or decrease button to adjust the top heater set
temperaturelevel.Thesettemperatureisadjustablefrom50to550Cinthis
type of operation.  To temporarily turn off the top heater. Simultaneously
pressboththe“Increase”and“decrease”button (#3 &#4 fromthecontrol
paneldisplayseepage8) .Thebottomdisplaywillshow“OFF”indicatingthe
topheaterisnowturnedoff.  Note: In order to reach the maximum
temperatureitisrecommendedthatanozzleisattached.
3. To set the desired bottom heater temperature press the selection button
repeatedly until the top display shows “bOt” and the middle display shows
“SEt”. The bottomdisplaywould show the currentset temperatureof the
bottomheaterfollowedbyasuffix“b”.
