APA 16617 - Scope of Delivery; Specifications; Explanation of Symbols; Safety Notes

9
2. Scope of delivery
3. Specications
4. Explanation of symbols
Corresponds to EC
directives
Labelled electrical
product may not be
disposed of in the
household waste
Devices with this
symbol may only be
operated in the
house (dry
environment)
Insulated housing
(protection class II).
Fuse,
here: Slow-burning,
1.6A
Recommended
battery capacity
Read the operating
instructions
Corresponds to the
requirements of § 21
of the German
Product Safety Law
(Produktsicherheitsg
esetz)
IP65
Protection class
Spray water
protected
5. Safety notes
• The warning triangle labels all instructions important to safety. Always follow these otherwise you could
injure yourself or damage the device.
• Only connect the device to a correctly installed socket. The voltage must correspond to the specication
on the type plate of the device.
• Do not trap the power cable and protect it from sharp edges, damp, heat or oil. The power cable of the unit
cannot be replaced. In the event that the cable is damaged, the unit must be disposed of.
• Do not operate the device or immediately pull the plug if it is damaged or you suspect it may be defective.
In this case, contact our technicians.
• Pull the plug when the device is not in use.
• Keep packaging materials, especially plastic and plastic bags, away from children. Risk of suocation!
• Remove all plastic from the device before use.
• Lay the mains cable in such a way that you are not hindered by it, and no one is able to accidentally pull it.
• Disconnect the battery charger from the power supply after charging.
• Keep the charger in a place that cannot be accessed by children or unauthorised persons.
• Never operate the device in the vicinity of ammable materials or in an environment prone to explosion.
• 1x Charger • 1 x Operating instructions
• 1 x Adapter charging cable with pole callipers • 1 x Adapter charging cable with eyes
Dimensions: 180 x 80 x 45 [mm]
Weight: 0.465 kg
Long mains cable: 1.50 m
Length of charging cable: 1.00 m + 0.50 m adapter charging cable
Input: 220-240 V AC 50/60 Hz
Output: 6 V mode: 7.2 V DC 2.0 A
Motorbike: 14.3 V DC 2.0 A
Auto: 14.3 V DC 4.0 A
Battery capacity: 6 V min 1.2 Ah max. 14 Ah
12 V min 1.2 Ah max. 120 Ah
Protection class: IP65 (only device housing, not connection and charging cable)
Ambient temperature: -5 °C to +40 °C
