Pre-amplifier
Technical Specifications
Outputs
Output stereo zone 1 balanced Euroblock connector 6 dB, 2 V,
100 ohm
Output stereo zone 1 unbalanced Cinch connector 0dB, 1 V, 100 ohm
Output stereo zone 2 unbalanced Cinch connector 0dB, 1 V, 100 ohm
Frequency response 20Hz - 22 kHz
Noise > 93 dB
THD < 0,008 %
Crosstalk > 70 dB
Max nominal gain +6 dB
Max output voltage +19 dBV, 9 V
Insert pcb for signal-processing Pcb ready, processors optional
Tone control zone 1 and 2 Bass 75 Hz +/-10 dB treble 10 kHz
+/-10 dB
Music and micmix level control 0-10 V VCA operated
Chime level 2-Tone, > 1 V
Priority outputs Open collector zone 1 and 2, max
24 V, max 50 mA
Line inputs
Line a to d Cinch connectors l & r channel
Line a to d sensitivity Trim from 330 mV/ -10 dBV to 5,3
V / +15 dBV
Line a yo d impedance 17 kΩ
Line a to d max input level +20 dBV
