Operation – Operation Procedures
10 Smart-UPS® VT 10-40 kVA 400V, 208V, 200V – Operation 990-2282A-001
How to turn into normal operation
Single System – turning into normal operation from internal bypass.
Single System – turning into normal operation from external bypass.
Caution
Never attempt to switch back the UPS into normal operation till you have verified that there
are no internal UPS faults.

Check that the UPS is in bypass. The green
(
LOAD ON) and the yellow (BYPASS) LEDs are
lit.

Turn the mechanical bypass lever downwards
into a horizontal position to deactivate the
internal bypass operation.

Press ESC to return to the previous menus and
turn out of bypass from the display via
Control–UPS out of bypass–Yes, UPS out
of bypass.

Check that the UPS is in normal operation.
The yellow (
BYPASS) LED turns off and the
green (
LOAD ON) LED remains lit.
Caution
Never attempt to switch back the UPS into normal operation till you have verified that there
are no internal UPS faults.

From the external MBP: Turn the output
switch (
Q002) to position “1”(ON).

From the UPS: Check that the yellow
(
BYPASS) LED is lit and the green (LOAD
ON
) LED is lit.

From the external MBP: Turn the bypass
switch (
Q003) to position “0” (OFF).

From the UPS: Turn out of bypass from the
display via Control–UPS out of bypass–
Yes, UPS out of bypass.

From the UPS: Check that the UPS is in
normal operation. The yellow (
BYPASS)
LED turns off and the green (
LOAD ON) LED
remains lit.

APC Smart-UPS VT Specifications

General

Noise level	55 dB
Output power	24000 W
Input frequency	40/70 Hz
Maximum current	41 A
Output power capacity	30 kVA
Emergency Power Off (EPO)	Yes
Battery type	VRLA
Dimensions (WxDxH)	559 x 813 x 1499 mm
Nominal input voltage	400 V
Certification	C-tick, CE, EN 50091-2, EN/IEC 62040-3, IEC 61000-3-2, IEC 61000-3-3, ISO 14001, ISO 9001, VFI-SS-112
Product color	Black
Battery recharge time	5 h
Operating altitude	0 - 999.9 m
Non-operating altitude	0 - 15000 m
Storage temperature (T-T)	-15 - 45 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	85078000

Weight and Dimensions

Weight	629090 g
Package weight	660000 g
